Epiphan AV.io SDI+ SDI-to-USB Capture Card, Works with SDI video sources, including: SD-SDI, HD-SDI, and 3G-SDI
The Epiphan AV.io SDI+â„¢ brings USB plug-and-play convenience to your SDI sources. You can easily capture 1080p video from any SDI camera or device with nearly zero latency.
| Brand: | Epiphan |
|---|---|
| Model: | AV.io SDI+ |
| Connectors: | SDI (BNC-style), USB 3.0 B-Type connector |
| Interface: | USB 2.0, USB 3.0 |
Request a Quotation
Epiphan AV.io SDI+ SDI-to-USB Video Capture Card Specifications:
- Manufacturer: Epiphan Video
- Model: EC20
- Interface: USB 3.0, USB 2.0
- OS drivers: UVC and UAC device
- Dimensions: 3.54″ × 2.36″ × 0.91″ (90 mm × 60 mm × 23 mm)
- Connectors: SDI (BNC-style), USB 3.0 B-Type connector
- Input: 3G-SDI, HD-SDI, SD-SDI (including embedded audio for 3G-SDI and HD-SDI), 3.5 mm analog (audio)
- Input resolution: Up to 1920×1080
- Output formats: Up to 1920×1200, 60 fps
- Output color space: YUV 4:2:2
- Capture latency: Near-zero (third-party applications may add to capture delay)
- SDI audio (input): 16-bit and 24-bit PCM encoded audio 48 kHz (audio capture supported from 3G-SDI and HD-SDI*)
- Audio output: 16-bit 48 kHz stereo audio
- LED: One LED to indicate status (power, readiness, operation in progress)
- Power consumption: <400ma
- OS support: Windows 10, 11, and up, Mac OS X 10.10 and up, Linux distribution with kernel 3.5.0 or higher supported
Epiphan AV.io SDI+™ brings USB plug-and-play convenience to your SDI sources. You can easily capture 1080p video from any SDI camera or device with nearly zero latency, bringing in audio through HDMI, the 3.5 mm input, or both. This card is compact and based on tough-as-nails technology that’s even been used in space, so you can confidently carry it wherever there’s video to capture.
Epiphan AV.io SDI+ SDI-to-USB Video Capture Card Key Features:
Tailored to your installation
AV.io SDI+’s Config Tool allows setting specific EDID for HDMI input, customize the output resolution & label each device, simplifying workflow for any project, particularly those that use multiple units in the same system.
Elevate your favorite apps
You can use AV.io SDI+ with any program that accepts USB as a video source. That includes video conferencing apps like Zoom and Microsoft Teams as well as streaming software such as Wirecast and OBS.
Size and scale effortlessly
There’s no need to think about video scaling or aspect ratios with this capture card. AV.io SDI+ will automatically adjust your image based on the software you’re using, delivering superior video quality.
Epiphan AV.io SDI+ SDI-to-USB Video Capture Card Resources:
